齒數(shù)

隆德型號

外圓直徑

節(jié)距圓直徑

主要尺寸

參考重量

PDF圖紙

DXF圖紙

De

Dp

L1

L2

C

Y

P

G

V

X

b1

B2

鏈輪

QD套

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

Lbs

36

LD80-3A1-36T-E

E

12.030

11.474

3 1/2

3 7/64

3 27/64

6

1/4

31/64

1/8

5/8

1 5/8

0.557

2.863

65.10

55.10

請咨詢

請咨詢

42

LD80-3A1-42T-E

E

13.940

13.382

3 1/2

3 7/64

3 27/64

6

1/4

31/64

1/8

5/8

1 5/8

0.557

2.863

81.90

71.90

45

LD80-3A1-45T-E

E

14.900

14.336

3 1/2

3 7/64

3 27/64

6

1/4

31/64

1/8

5/8

1 5/8

0.557

2.863

75.30

65.30

52

LD80-3A1-52T-E

E

17.130

16.562

3 1/2

3 7/64

3 27/64

6

1/4

31/64

1/8

5/8

1 5/8

0.557

2.863

90.00

80.00

60

LD80-3A1-60T-F

F

19.680

19.107

3 15/16

3 43/64

4 3/64

6 5/8

13/16

3/64

1/8

3/16

2 1/2

0.557

2.863

112.00

100.00

68

LD80-3A1-68T-F

F

22.230

21.653

3 15/16

3 43/64

4 3/64

6 5/8

13/16

3/64

1/8

3/16

2 1/2

0.557

2.863

132.00

120.00

76

LD80-3A1-76T-F

F

24.780

24.198

3 15/16

3 43/64

4 3/64

6 5/8

13/16

3/64

1/8

3/16

2 1/2

0.557

2.863

150.00

138.00

95

LD80-3A1-95T-F

F

30.830

30.245

3 15/16

3 43/64

4 3/64

6 5/8

13/16

3/64

1/8

3/16

2 1/2

0.557

2.863

208.00

196.00
