隆德鏈號

鏈條類型

附件尺寸

破斷載荷

PDF圖紙

DXF圖紙

P

G

L

C1

C2

F

d4

d5

mm

mm

mm

mm

mm

mm

mm

mm

LDC2040S-SS

A系列

25.40

19.10

9.50

11.10

13.50

20.50

3.40

5.50

請咨詢

請咨詢

請咨詢

LDC2040R-SS

LDC2050S-SS

31.75

23.80

11.90

14.30

15.90

25.00

5.50

6.60

LDC2050R-SS

LDC2060S-SS

38.10

28.60

14.30

17.50

19.10

32.90

5.50

9.20

LDC2060R-SS

LDC2080S-SS

50.80

38.10

19.10

22.20

25.40

43.50

6.60

11.00

LDC2080R-SS

LDC2060S-H-SS

38.10

28.60

14.30

17.50

19.10

32.90

5.50

9.20

LDC2060R-H-SS

LDC2080S-H-SS

50.80

38.10

19.10

22.20

25.40

43.50

6.60

11.00

LDC2080R-H-SS

LDC208B-S-SS

B系列

25.40

23.20

12.70

11.10

13.50

20.50

4.50

5.50

LDC208B-R-SS
